Specifications:
Model
VBS0407
Cutting height
400 mm (15.7”)
Cutting depth
700 mm (27.6”)
Cutting length
3/4.5/6 M
Table support width
Outer table
1600 mm (63”)
Inner table
Blade size
6200 x 54 x 1.6 mm (244.1” x 2.1” x 0.063”)
Blade speed
15-75 m/min (50 to 250 fpm)
Cutting feed
Servomotor (2-500 mm/min)
Motor
Blade drive
5.5 kW (7.5 HP)
Hydraulic pump
1.5 kW (2 HP) x2
Coolant pump
0.75 kW (1 HP)
Feed servomotor
1 kW
Table height
1500 mm (59.1”)
Floor space
10100L x 4100W mm (397.6” x 161.4”) (6M)
Machine height
3400 mm (133.9”)
Machine weight (approx.)
14500kgs (31967lbs) (6M)
