DIN-Rail Embedded System - DRPC-230-ULT5

Features:

Whiskey Lake Core™ i5-8365UE
Triple GbE LAN Ports
Multiple USB 3.2 Gen 2 (10Gb/s)
Multiple COM Ports
Modulized Flexible Expansion

Expandable Layer

DRPC-230 panel PC is designed to achieve AI inference and PoE applications through its expansion feature. The industrial computer system is compatible with IEI's own accelerator cards (Mustang-V100-MX8, Mustang-V100-MX4) and PoE cards (GPOE-4P, GPOE-2P).

For PoE cards, DRPC-230 has reserved a 60W internal power to provide. DRPC-230 is also possible to expand I/O through the second layer; its modularized flexibility could best fit users' preferences.

Specifications:

Model Name		DRPC-230-ULT5-i5/S	DRPC-230-ULT5-i5	DRPC-230-ULT5-C/S
Chassis	Color	Black and Silver
	Dimensions(WxDxH)	190 x 150 x 81mm	190 x 150 x 127mm	190 x 150 x 81mm
	System Fan	Fanless
	Chassis Construction	Extruded aluminum alloy
Motherboard	CPU	Intel® Core™ i5-8365UE Processor(Whiskeylake-U)		Intel® Whiskey Lake Celeron™ 4205U
	Chipset	SoC
	System Memory	2 x DDR4 2400Hz SO-DIMM (up to 32GB)
Storage	SATA	1 x 2.5" SATA 6Gb/s HDD/SSD bay
I/O Interfaces	USB 3.2 Gen 2	6		4
	USB 2.0	1 by pin header		2
	Ethernet	2 x Intel® I210 GbE LAN (colay Intel® I211) 1 x Intel® I219 GbE LAN
	COM Port	4 x RS-232/422/485 with AFC (DB9) 2 x RS-232 (RJ-45)
	Digital I/O	8-bit by pin header
	Display	1 x Lockable HDMI, 1 x DP
	TPM 2.0	Pin header
	Others	1 x Power button 1 x LED for power (green) 1 x Reset button 1 x LED for HDD (yellow) 1 x AT/ATX switch
Expansions	PCIe Mini	1 x Full-size (PCIe/USB 3.0/SATA)
	M.2	1 x 2230 A-Key (PCIe/USB 2.0)		1 x 2230 A-Key(PCIe)
	Backplane	1 x PCIe Gen3x4, 1 x USB2.0		-
	SIM	1x On-board SIM slot
Power	Power Input	3-pin terminal block: 12~24V DC *Reserved internal power (60W)
Power	Power Consumption	12V @ 4.98A
Reliability	Mounting	DIN-Rail
	Operating Temperature	-20 ~ 60°C
	Storage Temperature	-40 ~ 85°C
	Humidity	10 ~ 95% non condensing
	Operating Shock	Half-sine wave shock 5G, 11ms, 100 shocks per axis, IEC68-2-27
	Operation Vibration	MIL-STD-810G 514.6C-1 (SSD)
	Weight ( Net/Gross)	2.9KG/3.2KG	3.2 kg/ 3.5kg	2.9KG/3.2KG
	Safety / EMC	CE, FCC
	Watchdog timer	Programmable 1~255 sec/min
OS	Supported OS	Microsoft® Windows 10, Linux
