Tube Punching Machine PDM-Y-3000

Tube Punching Machine PDM-Y-3000

Technical Details:



CNC profile and pipe punching machine

Maximum pipe diameter 90 mm

Very precise progress with servo motor and planet reduction gear

Hydraulic punching

15 tons hydraulic press

Total motor power 5.5 kW

Pneumatic profile-pipe retaining clamp

Blowing at the core automatically and burr throw

Automatically activated hydraulic oil cooler and fan

Timed automatic lubrication for working components

Switch adjustable hydraulic press

CNC system and 4,3” touch screen

Manual or automatic operation on the screen

To see daily/total amount of production on the screen

To follow error messages on the screen and on the watch page

Foot pedal or button control optionally

Ability to record programmes

Standard machine length for punching 3000 mm

Maximum hydraulic pressure 160 bar

Electrical panel safety lock and panel lock with key

Two years guarantee; technical service and training confidency by CANSA MAKINA

Suitable for CE,

Maximum profile size 40X80 – 60X60 mm
