CPU

LGA1150 Intel® Xeon® E3, Core™ i3, Pentium® or Celeron® processor supported

System Chipset

Intel® C226

BIOS

UEFI BIOS

System Memory

Four 240-pin 1600/1333MHz dual-channel DDR3 & DDR3L SDRAM ECC and non-ECC unbuffered DIMMs support up to 32GB memory

Ethernet

GbE1: Intel® I217LM with Intel® AMT 9.0 support

GbE2: Intel® I210-AT PCIe controller with NCSI support

I/O Interface

4 x RS-232

1 x RS-422/485

1 x LPT

1 x 6-pin wafer for KB/MS

1 x mSATA (colay SATA port 6) (support SATA 6GB/s signal only)

6 x SATA 6GB/s (RAID 0, 1, 5, 10 supported)

8 x USB 2.0 (4 by pin header, 4 by backplane pin header)

4 x USB 3.0 (2 by rear IO, 2 by pin header)

Digital I/O

8-bit digital I/O (4-bit input, 4-bit output)

Super I/O

Fintek F81866

TPM

1 x 20-pin (2x10) header

SMBus

1 x 4-pin wafer

Audio

Supported by IEI AC-KIT-892HD Audio Kit

Display Interfaces

VGA (up to 1920x1200 @ 60 Hz)

iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160 @60 Hz)

LAN

2 x 2-pin headers for LAN1 Link LED, LAN2 Link LED

Expansion

PCIe signal and PCI signal via golden finger

PCI signal by ITE IT 8892 (PCIe to PCI bridge)

1 x Full-size PCIe Mini card slot (colay mSATA)

Watchdog Timer

Software programmable, support 1~255 sec. system reset

Power Supply

5V/12V, AT/ATX support

Fan

1 x 4-pin smart fan connector (CPU fan)

1 x 4-pin smart fan connector (system fan)

Power Consumption

5V@3.55A, 12V@0.37A, Vcore_12V@7.61A, 3.3V@1.55A, 5VSB@0.13A

(Intel® E3-1240 v3 3.4GHz CPU with 16GB (4x4GB) 1333MHz DDR3 memory)

Graphic

Intel® HD Graphics Gen 7.5 supports DX11.1 and OpenCL 1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode

Operating Temperature

-20°C ~ 60°C

Humidity

5% ~ 95%, non-condensing

Dimensions

338 mm x 126 mm

Weight

GW 1200g / NW: 420g

Front Panel

1 x Front panel (Power LED, HDD LED, Speaker, Power Button, Reset Button)

I2C

1 x 4-pin wafer

iRIS Remote Management Module

1 x iRIS-2400 slot
