Motion Control Products Posys 3004

The POSYS® 3004 (Designed & Made in Germany) is a PC/104 form factor board dedicated to high performance motion control applications with extensive interpolation functionality. The POSYS® 3004 is designed to control up to 4 axes of servo and stepper motors and provides hardware linear, circular, Bit Pattern and continuous interpolation which allow performing the most complex motion profiles. Update rates per axis do not exist as each axis runs in absolute real-time mode simultaneously which makes these boards to one of the best performing motion controllers for up to 4 axes in the market.

The POSYS® 3004 in addition provides an on-board DOS-like RTOS with 8 MB SDRAM and 8 MB Flash RAM with integrated Web, FTP and Telnet server for communication purposes via the x3 RS232/RS485 serial, x1 Ethernet, x1 USB1.1 or x2 CAN 2.0b interface which enhances this board for a variety of connection solutions. This allows maintenance, executing, monitoring, updating and diagnostics to be performed easily via network, field bus, Internet or Intranet. The multitasking capability allows up to 12 tasks to be executed simultaneously. Together with the CoDeSys IEC 61131-3 Runtime library integrated, this board can be used for almost any kind of motion control application. We recommend AMC,s digital servo drives and the Click & Move®* software. This software is based on PLC Open®* and supports the POSYS® 3004 directly.
