IDM Instruments Pty Ltd

Laboratory Heated Press L0002 & L0003

Laboratory Heated Press L0002 & L0003 are designed for pressing or helping to form samples between two platens. Two digital temperature controllers enable the platens to be heated or cooled and even set process times for heating and cooling. A digital panel meter is used to display the compression force (kgf) enabling fast and accurate testing.

Applications:


• Moulding Plastic
• Moulding Rubber
• Moulding Composites

Standards:


• ASTM D 4703

Features:


• Digital Panel Meter • Accuracy: ≤ ± 1% FS
• Digital temperature controllers: • Temperature: Ambient to 300ºC ±2ºC
• Platens: 300mm x 300mm
• Maximum Stroke: 150mm
• Maximum daylight: 150mm
• Digital pressure gauge indicating tonnes
• Hydraulic Hand pump
• Timer: 0 - 9999
• Auto Zero function
• Sample Rate: 5 to 100 per second (selectable)
