Wizlogix Pte Ltd

PCB Layout Design

Wizlogix Pte Ltd hires the best for your benefit. Post a rigorous selection process, our design engineers are trained via 3 to 6 month programs on software implementation, Gerber checking and customer relations amongst others. Our engineers constantly upgrade their skills through the Continual Industry Standards Training and Certification Programme and are awarded with the IPC Certified Interconnect Designer and IPC Advance Certified Interconnect Designer certification.

Experiences and Strengths

• High Speed
• FPGA Design
• HDI Design
• High Layers
• Mixed Signal
• Blind/ Buried Via
• TDR Traces
• Length Matched Traces
• Fine Pitch BGA
• Constraint Manager
• DFM
• DFT
• DFA
• Customer Specific Requests
• IPC CID Certified Design Engineers

Thoroughly proficient in manual placements and routing of boards, the skilled team generates all necessary Gerber manufacturing files. Internal design reviews are executed at every step while working closely with the client.

Design Tools

• Mentor Graphics – PADS
• Mentor Graphics – Expedition
• Altium Designer
• Cadence Allegro
• Cam 350/Camtastic 2000

Design Verification

• DFM & DFT
• IPC & Mil Standard
• EMC/EMI
• High-Speed Rules
• Gerber Checking using CAM Tool
• In-Process Cross QC

Design Deliverables

• Fabrication Drawings
• Assembly Drawings
• Gerber Data
• Drill Data
• Design Database
• Customized Output Files
