Wrenches and pulse tools static micro test bench

Wrenches and pulse tools static micro test bench

Microbench – Static transducers micro test bench

An ideal solution for testing wrenches and power-tools. Light weight and small size, to be easily positioned along the assembly lines.

Thanks to SCS wireless technology, it’s possible to connect wireless transducers. Also available with WiFi radio module to be programmed remotely from SQnet+.

Functions

• Tools test: wrenches (electronic/digital, click), power tools (excluding pulse tools and impact ).
• Automatic detection of the click point of click wrenches.
• Statistical Process Control: Measurement of machine capability (Cm, Cmk) and X, R charts.
• Test according to ISO 6789
• Reaction system for testing and calibration of torque
• Database with tools archive, scheduling and execution of tests, storage of results
• Compared tests for wrenches with torque comparison between the bench and the wrench under test
• External transducers connectivity for special tests
• Test clockwise and counterclockwise
• Mechanical joint simulators for testing of power tools
• Statistics and report
• Real time traces on the monitor
• Equipped with 3 static torque transducers (10 Nm, 50 Nm, 250 Nm)
• Programming in local, or remote through management software for quality control of the production line
• Radio communication to external systems
• Local database or server
• Torque accuracy less than 0.5% according to DIN 51309
• Battery powered
