Leeson Elevator Duty Motor LM29673

Leeson Elevator Duty Motor, 50 HP, 3 Ph, 60 Hz, 575 V, 3600 RPM, 160TZ Frame, OPEN - LM29673

KEY FEATURES

• Intermittent duty
• Suitable for Wye-Delta starters
• 1.0 service factor and 70°C ambient rated
• Three bolt circles, 12 mounting holes, and face mounting to accept both the IMO and Allweiler pumps
• 10 foot long leads, spliced 40 inches from motor to prevent wicking of hydraulic fluid
• Thermostat leads are marked P1 and P2
• Class F insulation
• Two stainless steel nameplates, one shipped separate for remote mount
• UL recognized component listing and CSA approved
