Kira Valves & Engineering

SPECIFICATIONS

Threads confirm to ASME B1.20.1 (NPT), DIN 2999 & BS 21, ISO 228/1 & ISO 7/1

Investment casting, Blow-out proof system

PTFE Seat, Full Bore

Lockable Handle

Test and Inspection to API598

Also Available Butt Weld end and Socket Weld ends

DIMENSIONS (in mm) - PN63

DN

d

L

H

W

S

T

M

N

V

P

K

Weight(kg)

8

11.6

64.5

54

102

35.5

21.5

29

5

29.7

10.5

0.41

10

12.7

64.5

54

102

35.5

21.5

29

5

29.7

10.5

0.41

15

15

66

57

102

38

24

33.2

5

30.1

10.5

0.52

20

20

83.5

66

120.5

43

28

37.5

6.5

36.5

13.5

0.71

25

25

95

76

158.5

54

35

42.4

8

40.6

15.5

1.08

32

32

111.2

81

158.5

65

45

50.9

8

41.8

15.5

1.71

40

38

129.8

98

188

75

55

59.4

9

48.5

17.5

2.35

50

50

151

106

188

88

66

73.4

9

49.4

17.5

3.55

65

65

184

138

245

114

86

96.5

12

72.1

33

8.9

80

80

209

154

245

132

100

81

12

65.6

33

14.3

100

100

234.4

178

320

158

125

102

16

78.2

39

1W

23.4

MATERIALS OF CONSTRUCTION

ITEM

PARTS

MATERIAL

1

Body

ASTM A351-CF8M & ASTM A216-WCB

2

Cap

1.4408 1.0619

3

Ball

ASTM A351-CF8M / 1.4408

4

Stem

PTFE / RFTE

5

Gland Nut

ASTM A276-316

6

Ball Seat

PTFE / RFTE/CTFE

7

Body Seal

PTFE

8

Packing

PTFE

9

Thrust Washer

PTFE

10

Spring Washer

AISI 304

11

Stem Nut

ASTM A194 Gr.8

12

Bolt

ASTM 193 B8

13

Bolt Nut

ASTM 193 B8

14

Handle

ASTM 167-304

15

Lock Device

ASTM 167-304

16

Handle Sleeve

PVC
