Specifications

Screwed ends to BS21

Full Bore

Male / Female ends also available up to 2"

MATERIALS OF CONSTRUCTION

Part

Material

Body

Forged Brass

Body cap

Forged Brass

Stem

Special Brass rod

Ball

Forged Brass (chrome plated)

Seat

PTFE

O ring

PTFE

Handle

Steel (vinyl sleeve)

DIMENSIONS ( in mm)

A

1/4"

3/8"

1/2"

3/4"

1"

11/4"

11/2"

2"

21/2"

3"

4"

DN

10

10

15

20

25

32

40

50

65

75

100

B

42

42

50

55.6

66.6

75.7

87.2

102

133.2

148.2

171

C

41.7

41.7

43.2

45

54.3

65.3

79.7

87.5

109.4

117.4

131.9

D

75

75

85

85

104

448

150

150

245

245

280
