TL-143 X Shape Heater Filling Machine
Tongli Machinery TL-143 X shape heater filling machine is designed special for filling MgO powder inside of X shape aluminum heater. It’s different from our other tubular heater filling machines.
*Adapt the double center guarantee structure.
*Speed regulating motor vibration.
*PLC controlled.
*Frequency control of motor speed.
*Man-machine interface.
Technical parameters:
- Power supply: 220V±10% 50hz.
- Air supply: 4-7kg/cm2.
- Rated power: 1550w.
- Applicable tube length: 250-1500mm.
- Filing speed: 350mm/min.
- Machine size: 1880*850*3300mm(1 meter tube length).
- Net weight: 650kg.
Required information when ordering our TL-143 X shape heater filling machine
*Tube length.
*Max.diameter after welding coil with terminal pin.
*X shape heater drawings.
*Electrical supply (for example, single phase 220v 50hz).
*To be supplied by customer before delivery: About min.16pcs coil and terminal pin set and min.12pcs aluminum X shape sheath for testing machine.
Notes: All the information above, which may be subject to change, is offered solely for your reference, and should not be taken as a warranty or representation for which we assume any legal responsibility.
