SMD Stencils(solder paste and adhesive stencils) are an absolute necessity for SMT circuit board assembly.SMD stencils from Headpcb are manufactured using laser technology, which ensures a constant process quality through its high level of precision.

Our SMD Stencils fulfil the most stringent quality requirements with optimal register accuracy and cutting precision. The precise axial tolerance of ±2um and a repeat accuracy of ±3um offers optimal conditions for solder paste printing, even for the smallest high-tech components.

SMD Stencils advantages from Headpcb over other PCB suppliers

• 14 years'quality reputation of SMD Stencils
• Extremely competitive price,no hidden cost
• All laser cut with high precision
• Excellent for even smallest components and high volume printing
• 99% On-time delivery,100% test and inspections
• Really fast response and execution
• Money back guaranteed

SMD Stencils Capabilities

• Material used: Stainless Steel
• Stencil Type: Framed and Frameless
• Stencil thickness: .001 - .016 inches
• Minimum cut width: .002 inches
• Maximum size: 29"x29" inches
• We make all aperture modifications necessary
• Aperture tolerance within .00025 inches
• Allow for fiducial data
• Allow for panellized data
