CONVENTIONAL MULTILAYER RIGID PRINTED CIRCUIT BOARDS

CONVENTIONAL MULTILAYER RIGID PRINTED CIRCUIT BOARDS

Winonics is an industry leading manufacturer of Multilayer PCBs. Conventional Multilayer PCBs range from 3 to 24 layers, use conventional drilling and plating technologies and are single lamination constructions. Our conventional multilayer PCB capabilities are served by decades experience from a diverse team of engineers, specialists, experts, and operators.

Capabilities:

• Layer count 24+
• Panel Size up to 21”x24”
• Mixed Materials
• High Aspect Ratio
• Backdrilling
• Edge plating
• RF Microwave
• Cavities, countersunk holes or depth milling
• Heavy copper
• Controlled impedances
• All Surface Finishes
