Topvert P1 Series AC Motor Drive

Features

• 16 Bit Microprocessor Sensor less vector control

• V/F mode & Sensor less Vector mode-------open loop control

• V/F + PG mode & Vector + PG mode---------close loop control

• Auto tuning

• Over load capability 125%, 1 minute

• Automatic torque boost & slip compensation

• Output frequency 0.1~600Hz, Programmable

• 16-step PLC run & 16 step preset speed

• PID feedback control & PG feedback control

• 2 accel./decel time selection (0.01~60000 sec)

• Pump control and automatic energy -saving.

• Process follower - 10~10VDC, 0~10VDC, 4~20mA

• MODBUS communication RS-485 (Baud rate 125000 bps)

• Coast or ramp to stop

• Random V/F curve & Automatic voltage regulation (AVR)

• Auto-optimum accel./decel. time & S-curves

• Sleep/Wakeup function & Auto Restart after fault

• Mechanical braking release control function

• Auto Restart after fault & Fault history up to 16 records

• Module/ Heatsink temperature display & Pre-warning

• Low noise-- Carrier frequency up to 18 kHz

• Bi-Directional Speed search (Reentry to spinning load)

• Password protection & User define Multi-function display

• DC bus capacitor life time monitoring & Auto carrier frequency adjust

• Over-current/Over-voltage stall prevention & Over torque detection

• Full protection (LV,OV,OC,SC,OH,OL…etc.)

• Programmable Multi-Function input terminals

• Programmable Multi-Function output terminals

• Programmable Analog output voltage & current signals

• Programmable Digital pulse output

• Encorder style knob with 0.01Hz resolution

• Removable Keypad operator up to 150 meters.

• Sink/Source (NPN/PNP) mode selectable by user

• DC injection brake & Dynamic brake

• Electronic Thermal Relay & External Counter built-in

• Fan & Pump process control (Time/Fix amount circulation control)
