Sidewalls
Sidewalls are manufactured in a wide range of heights, from 40 mm up to 600 mm.
All sidewalls can be produced with a fabric reinforcement insert, particularly recommended for heights over 140 mm and necessary for heights of 160 mm and above.
The design of our sidewalls offers great vertical resistance, which adds greater stability to the belt and maintains a high degree of flexibility while allowing it to adapt to lower diameter pulleys.
It is important to observe the minimum diameters required in order to achieve the longest service life possible.
We generally recommend the following:
D1 = 4 x sidewall height.D2 = 2,5 x sidewall height.
Depending on the quality of the rubber, it’s necessary that you get a separate calculation for each specific project.
