MiniPack XL

MiniPack XL

RND Automation's MiniPack XL is the Extended Load version of our popular MiniPack, Horizontal Form Fill and Seal machine.  When your process requires multiple cavity blisters at a high output rates, the customizable length load area allows products to be loaded with human operators or robotic automation.

The MiniPack XL can also be formatted to run multiple forms on the same machine at the same time.  You can switch between forms on-demand and on-the-fly.

The MiniPack XL is a great choice when you have a series of additional operations such as pin hole detection, card or literature feeding, multiple product inspections, high output rates or when you just need extra room to load your products.

• Max Web Width: 12.6″ (320mm)
• Max Index Length: 12.0″ (305mm)
• Max Package Draw Depth: 4.0″ (102mm)
• Load Area Length: Fully customizable
• Max Film Thickness: Up to 20mil
• Max Film Roll Diameter: 16.0″ (406mm)
• Machine Speed: 10-18 indexes per minute
