EM271 Energy Meter for NIBE F2040

EM271 is the perfect solution for NIBE F2040 as all loads are monitored by split core Current Sensors to improve installation time and safety. Only one voltage reference is required to allow for monitoring the system and is connected into the main EM271 device from the main incoming supply.

All variables are monitored with high accuracy and presents kWh equivalent to Class 1 for load monitoring when connected correctly as per NIBE wiring and installation instructions.

The pulse output provided with the system can be connected to the NIBE SMO controller for monitoring as an on-board meter to comply with RHI Annex 7.

It's possible to monitor up to 3 single phase loads and display accumulated energy consumption.

Features of EM271

• Monitoring of F2040, MegaCoil Immersion Heater and ELK.
• Connection of up to 3 extendable wired CS's.
• User friendly two-button interface.
• DIN rail mount in consumer unit.
