MC series connectors

MC series connectors

MC series connectors

MCV, M23, Cordset, Shielded Cable, Not shielded to coupling nut, 12 Pole, Female Right Angle, 2M, 6A/2A, PUR, Black

Description

MC series connectors, sometimes referred to as M16, M23, or M27 connectors, provide rugged plug and play solutions for demanding industrial applications. Mencom offers molded cable, field wired connectors, and panel mount receptacles to meet your specific requirements.

Specification

PRODUCT TYPE

Cables

COMPONENT TYPE

Cordset

MENCOM SERIES

MC

PIN COUNT

12

HOME RUN PIN COUNT

12

GENDER

Female

ORIENTATION HEAD 1

Female Right Angle

MATING THREAD / TYPE HEAD 1

M23

COUPLING THREAD GENDER1

Female

ORIENTATION HEAD 2

N/A

MATING THREAD / TYPE HEAD 2

N/A

COUPLING THREAD GENDER2

N/A

WIRE GAUGE

18

UPPER AWG

N/A

LOWER AWG

N/A

VOLTAGE RATING

300

AMPERAGE RATING

6/2

CABLE LENGTH IN METERS

2

CABLE LENGTH IN FEET

6

CABLE O.D.

0.38

COLOR CODE

N/A

CABLE JACKET MATERIAL

PUR

JACKET COLOR

Black

MOUNTING THREAD

N/A

MOUNTING STYLE

N/A

NUT

No

TERMINATION

N/A

SHELL / COUPLING NUT MATERIAL

Nickel Plated Brass

SHIELDING

Yes

GROUND WIRE

Yes

GLAND UPPER RANGE

0.38

GLAND LOWER RANGE

0.38

MCVHPIN

no

IP RATING

IP69

WEIGHT (LBS.)

0.760000
