PCB DESIGN

A printed circuit board (PCB) can be an asset or a liability for an electronic product.  For more than 25 years, we have designed PCBs for a variety of challenging applications.  Our designers are IPC certified and are skillful craftsmen who will work with you to design a quality PCB that meets all your requirements.

CAPABILITIES:

• High-Speed Digital Designs to GHZ+ on FR4 & High-Performance Materials
• Low-Level Analog, RF, LVDS, GTL+, PECL
• DDR/DDR2 & 3, Memory, DVI, Ethernet, USB2, PCIX, PCI

PRIMARY SOFTWARE PLATFORMS:

• Altium Nexus
• Any Netlist Format for Input
• CAM350 Pre-Fabrication Gerger Verification

EMC/EMI SIGNAL INTEGRITY ANALYSIS

• Termination & Topology Strategies
• Stack-Up, Impedance & Analysis

CIRCUIT BOARD DESIGN:

• Complete Traditional Printed Circuit Boards - 1 to 30 layers
• Micro-BGA, Micro-Vias, HDI, Impedance Control
• Pre-Layout Thermal Planning
• Low-Loss Materials, Metal Cores, Heat Plates

BOARD FABRICATION:

• Pre-Fabrication IPC Netlist
• Verification of Gerbers
• IPC Netlist Board Conformance
• Testing
