About this series
Efficient, streamlined and customer oriented processes in production, administration and service ensure punctual delivery, highest quality standards and ease of integration of our cameras. The company headquarters in Seefeld, Germany. Today SVS VISTEK is one of the most innovative manufacturers of industrial cameras with an international presence.
The SVCam-HR Series: Details on speed
The SVCam-HR series meets exclusive demands to resolution at very high speed. GigE Vision and Camera Link (PoCL) interfaces provide resolutions 11 to 29 megapixel at up to 11 fps.
An elaborately designed massive housing ensures excellent temperature management and allows fanless operation even with large sensors.
High-resolution sensors require special care in managing the homogeneity of the image. Excellent tap balancing, lens shading correction for demanding optical tasks and customizable defective pixel correction ensure outstanding linearity, homogeneity and low noise.
One of the most compact camera modules of its class
The M58 lens thread (FFD 11.48 mm / F-mount optional) has been designed so that almost all lenses can be connected using appropriate adapters and adjusted to optimum effect for your imaging task. The IO design features programmable IO logic, a sequencer, timer, SafeTrigger and an integrated 4-channel LED flash controller. The light controller integrated in the GenICam tree of the camera can be managed via any GenICam application (for example HALCON, MERLIC, MatLab, VisionPro) or the SDK. The high resolution permits an extremely wide field of vision and therefore makes the HR suitable for applications such as optical metrology, quality control and wide-field surveillance. The HR is available with Camera Link, Gigabit Ethernet or CoaXPress interfaces.
