4D16Q

Overview

Bussmann

Bottle Type D Fuses, D Series

Item# 4D16Q - FUSE, 4A, 500V

D Series Information

• 2~100 Amps
• 500VAC
• Fast Acting or Time Delay
• Diazed Bottle Type
• DIN Compliant

Diazed Fuses, commonly called "Bottle" Fuses, are available in five sizes. Each size fuse body has a different diameter to fit only into the appropriate screw cap and fuse base. Also, the fuse tips have different diameters, depending on their current rating. The diameter of the tip matches the diameter of the hole in the adapter screw to insure that no fuse with a higher rating than intended for the circuit can be installed. This prevents damage to the circuit or equipment the fuse protects. Additionally, fuses and adapter screws are color coded to avoid mismatching.

• Color Coded
• Trip Indicator
