Product Description
CQPI-31200-C2P
This human/machine touch screen interface is designated the CPQI-31200-C2P. It is classified as a part of the QuickPanel series of touch screen modules, which were developed and produced by General Electric. GE’s industrial automation manufacturing division no longer has this or any other of the QuickPanel units in stock, as they are out of production.
The CQPI-31200-C2P model is one of their 10.5 inch models, with the standard dimensions for this size of model. The width is measured at 9.57 inches/243 millimeters, a height of 12.48 inches/317 millimeters, and then a 3.05 inches/77.5 millimeters. This model weighs up to 7.71 pounds, or 3.5 kilograms.
The operational voltage required to power the CQI-31200-C2P ranges from as low as 85 to 132 volts of alternating current, and is nominal at around 120 VAC. 50 to 60 hertz is also an acceptable energy intake.
The model’s temperature factors in to the amount of voltage used, as well as the other equipment that is around this unit, which may heat it up. The optimal temperature range for this unit is a between 0 and 45 degrees Celsius, or 32 to 113 degrees Fahrenheit. To prevent overheating, these models are cooled by a Natural Air Convection unit, rather than an internal fan or forced air cooling system.
The CQPI-31200-C2P model is regarded as outdated and obsolete, but, after being refurbished and repaired by our repair technicians here at AX Control, it is able to run at optimal performance.
